Description
Decoiler,straightening line
10T hydraulic decoiler + loading trolley + hydraulic support
1 meter servo motor leveling machine
1*3m conveyor belt
1m*3m palletizer
Automatic shearing machine
| Production speed | About 15 meters/1 minute |
| Feed width | ≦1.3 meters |
| Side panel thickness | 30mm |
| Leveling thickness | ≦1mm cold rolled plate, galvanized plate |
80T mechanical punching machine
| Nominal force | 800 |
| Nominal force stroke | 4 |
| Number of trips | 35-80 |
| Slider stroke | 150 |
| Maximum mold height | 340 |
| Mold height adjustment amount | 80 |
| Slider bottom size (left and right × front and rear × thickness) | 560*420*70 |
| working desk size (left and right × front and rear × thickness) | 1000*550*90 |
| Workbench blanking hole size (left and right × front and back) | 360*180 |
| Die handle hole diameter | Φ50 |
| Main motor power | 7.5*4 |
| Use air pressure | 6 |
| Dimensions (length × width × height) | 1800*1180*2980 |
3-rollers rolling machine
Power supply: 380V 50HZ processable length: 720㎜
Processable diameter: 300㎜-450㎜, material thickness: 0.5-1㎜
Power: 0.75KW. Overall dimensions: 1000*550*1500
Work efficiency: 2-3 pieces/minute
Spot welding machine
- Power supply: 380V 50HZ, processable length: 680㎜
- Power: 50KVA Processable diameter: 300-450㎜
- Overall dimensions: 1100*700*1500, welding thickness: ≦1+1
- Air source pressure: 0.5Mpa. Working efficiency: 2-3 pieces/minute
- Seam welding machinePower supply: 380V 50HZ, processable length: 720㎜
Power: 125KVA Processable diameter: 300-450㎜
Overall dimensions: 1500*900*1700, welding thickness: ≦1+1
Work efficiency: 2-3 pieces/minute
Hydraulic expanding machine:
- Power supply: 380V 50HZ, mold height: 680㎜
- Power: 7.5KW Mold diameter: 356-343㎜
- Overall dimensions: 1100*700*1300. Hydraulic rated pressure: 16Mpa
- Work efficiency: 2-3 pieces/minute
- Hydraulic flanging machine:Power supply: 380V 50HZ, processing height: 680㎜
Power: 5.5KW Mold diameter: 356-343㎜
Overall dimensions: 1100*850*2000. Hydraulic rated pressure: 16Mpa
Work efficiency: 2-3 pieces/minute
- Hydraulic necking machinePower supply: 380V 50HZ, processing height: 680㎜
Power: 7.5KW Mold diameter: 356-343㎜
Overall dimensions: 1100*700*1300. Hydraulic rated pressure: 16Mpa
Work efficiency: 2-3 pieces/minute
- Pre-roll glue injection machine:
- The straight edge of the bottom of the barrel is pre-rolled and filled with sealant.The main technical parameters:
Input power: AC380V/50HZ. Total motor power: 6.2 kW
Work efficiency: 6/min. Workpiece diameter: 343mm
Equipment weight: 500Kg Workpiece thickness: 0.5-0.8mm
Overall dimensions: 1600*1000*1000.
Ring forming machine:
Power supply: 380V 50HZ, processing height: 680㎜
Power: 4KW Mold diameter: 356㎜
Overall dimensions: 1100*850*2000, air source pressure: 0.5Mpa.
Work efficiency: 2-3 pieces/minute
Double-end sealing machine
Power supply: 380V 50HZ, processing height: 500-680㎜
Power: 12KW Mold diameter: 356-343㎜
Overall dimensions: 2200*650*1600, air source pressure: 0.5Mpa.
Work efficiency: 2-3 pieces/minute
Pneumatic leak test machine:
The main technical parameters:
Input power: AC380V/50HZ. Work efficiency: 3 pieces/minute
Workpiece diameter: 300-400mm
Equipment weight: 550Kg Workpiece height: 600-700
Overall dimensions: 1700*1200*1000.
